K9 Roof Prisms

Roof prisms can revert and invert the image or bend the deflected light by the angle of 90°.
It is ideal for telescope and any optical instrument where it is desirable to take an inverted image from an objective, turn it right side up and bend it through a 90° angle in order to maintain the correct visual orientation.

Material:H-K9L Optical Glass

Dimension Tolerance:+0.0/-0.1mm

Surface Accuracy:λ/10 @ 632.8nm

Surface Quality:40-20

Roof Angle Tolerance:±3 arcsec

Other Angles Tolerance:±3 arcmin

Bevel:＜ 0.25mmX45°

Coating:Uncoated
